HP 1188A LOGIC CARD

HP 1188A LOGIC CARD Specification

Model No
1188A

Height
Standard PCB profile

Compatible Brand
HP

For Use In
printer

Connectivity Type
PCB Edge Connector

Noise Level
Silent operation

Weight
Approx 60g

Power Source
Powered via test system

Features
High reliability, secure PCB mounting, accurate logic signal routing, durable construction

Lead Time
1-2 Weeks

Pattern
Multi-layer PCB with labeled tracks

Capacity
1 Pcs/min

Size
180mm x 100mm x 18mm approx

Color
green

Storage Instructions
Store in anti-static bag

Product Type
logic card

Packaging
Individually packed

Application
Logic signal testing, digital circuit analysis

Operating Temperature
0C to 50C

Condition
New, unused

Mount Type
Plug-in card

Component Type
Digital logic circuitry

Input Voltage
5V logic compatible

HP 1188A LOGIC CARD Trade Information

Minimum Order Quantity
1 Piece

FOB Port
mumbai

Payment Terms
Cash Against Delivery (CAD)

Supply Ability
1000 Pieces Per Month

Delivery Time
3 Days

Sample Available
No

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About HP 1188A LOGIC CARD

The HP 1188A Logic Card, also known as the Formatter Board or Main PCB Board, is the central controller board of the printer. It manages all printer operations including print processing, scanner communication, USB connectivity, and system control functions. This board is commonly replaced when the printer experiences startup failure, communication issues, motherboard damage, or printing errors.

Key Features

Compatible with HP Laser MFP 1188 series printers
Supports printing, scanning, and USB communication
Original refurbished / pulled working board
Fully tested before dispatch
Easy installation and replacement
Stable and reliable printer performance

Compatible Models

HP Laser MFP 1188A
HP Laser MFP 1188W
HP Laser MFP 1188NW
HP Laser MFP 1188FNW

Part Numbers

SL-M2090NW
SL-M2091
SL-M2091W

Also Known As

Formatter Board
Logic Card
Main PCB Board
Motherboard
MPCA Board
USB Main Board

Common Problems Solved

Printer not powering on
Printer hanging or restarting
USB or connectivity issue
Printing communication failure
Scanner detection problem
Mainboard fault

Product Condition

Refurbished Original
Pulled from working printer
Professionally tested and cleaned

Package Includes

1 HP 1188A Logic Card / Formatter Board
