Epson Lx310 Power Supply Board

Epson Lx310 Power Supply Board Specification

Printer Type
Dot Matrix Printer

Model No
LX-310 Power Supply Board

For Use In
Epson LX-310 Printer

Print Technology
Dot Matrix

Weight
Approx. 117 g

Pattern
PCB Circuit

Compatible Brand
Epson

Size
Standard (As per LX-310) approx. 14.7 cm x 7.8 cm

Lead Time
1-3 days

Connectivity Type
Board Connection (Internal)

Year Built
2023

Power Source
AC 220-240V, 50/60Hz

Capacity
Standard

Product Type
Power Supply Board

Features
High durability, easy installation, stable performance

Color
Green (PCB) / Multicolor Components

Storage Instructions
Store in a dry, static-free environment

Height
Approx. 2.5 cm

Mounting
Pre-drilled mounting holes

Operating Temperature
0C to 40C

Material
FR-4 Epoxy Resin PCB

Output Power
Rated as per OEM (Approx. 55W)

Input Voltage Range
AC 100-240V

Output Voltage
DC 24V, 5V (Multi-output)

PCB Thickness
1.6 mm

Storage Temperature
-20C to 60C

Protection Features
Short circuit and overload protection

About Epson Lx310 Power Supply Board

The Epson LX-310 power supply is a dedicated internal Power Supply Unit (PSU) board designed for the Epson LX-310 dot matrix printer. It acts as a direct-fit replacement for repairing voltage regulation issues. Key specs include single-layered construction with a 200V-240V, 50Hz input (also 110V versions), ensuring stable printer operation.

Key Features and Specifications:

Compatibility: Designed for Epson LX-310 and LX-1310 dot matrix printers.
Function: Restores power regulation and ensures stable operation.
Voltage: Primarily 200V - 240V AC (50Hz), with some units listing 110V (60Hz).
Board Type: Single-layered.
Weight: Approximately 0.6 kg.
Condition: Available as new original parts or imported tested working units.

Efficient & Reliable Power Delivery

This power supply board provides stable DC 24V and 5V outputs suitable for powering your Epson LX-310 dot matrix printer. Its multi-output design and OEM-rated power output ensure consistent, trouble-free operation in professional environments, minimizing disruption and downtime.

Easy Installation & Broad Compatibility

Designed with pre-drilled mounting holes and a standard size as per the LX-310 printer requirements, this board is quick to install internally. It fits seamlessly into existing equipment, supporting easy upgrades or replacements for dealers, technicians, and end-users alike.

Long-lasting Durability & Protection

Constructed from robust FR-4 epoxy resin, the board offers heightened durability and longevity. Its built-in short circuit and overload protection secure the printer against common electronic faults, while the specified operating and storage temperatures support safe function in variable conditions.

FAQ's of Epson Lx310 Power Supply Board:

Q: How do I install the Epson LX-310 Power Supply Board in my printer?

A: Installation is straightforward: simply connect the board internally to the prescribed connections in the Epson LX-310 printer using the pre-drilled mounting holes for secure placement. Refer to your printer's service manual or consult a trained technician for detailed steps.

Q: What are the benefits of using a genuine LX-310 Power Supply Board?

A: A genuine LX-310 Power Supply Board delivers stable and efficient power, perfectly matched to the printer's requirements. It ensures reliable operation, reduces the risk of electrical faults, and upholds the printer's performance and safety standards.

Q: When should I consider replacing the power supply board in my Epson LX-310?

A: Replacement is recommended if the printer exhibits power issues, frequent resets, or fails to start. Upgrading to a new board can resolve these problems and restore full functionality, especially when the current board is damaged or malfunctions persist.

Q: Where should the power supply board be stored before installation?

A: Store the board in a dry, static-free environment to prevent damage from moisture or electrostatic discharge. Appropriate storage ensures the board retains its integrity and is safe for later installation.

Q: What protection features are included on this power supply board?

A: The Epson LX-310 Power Supply Board includes built-in short circuit and overload protection. These features help safeguard both the printer and the board itself from common electrical faults during operation.

Q: How does the board maintain stable performance in variable conditions?

A: The board is designed to operate within 0C to 40C and can be stored between -20C and 60C. Its durable FR-4 epoxy resin construction and robust electronic components ensure stable functionality, even in fluctuating environments.
