EPSON L3110 / L3115 Printer CCD SCANNER

About EPSON L3110 / L3115 Printer CCD SCANNER

1. Product Function and Description

• Purpose: This component replaces a faulty scanner assembly, addressing issues such as distorted images, blurry scans, white pages, scanner error messages, or a non-functioning scanner carriage.
• Scanner Type: Although often referred to as a "CCD" (Charge-Coupled Device) unit in aftermarket listings, it is technically a CIS (Contact Image Sensor) head scanner.
• Component Assembly: The unit typically includes the CIS sensor head, the motor (often a 5-pin configuration), and the scanner gear assembly, allowing for a complete repair of the scanning mechanism.

2. Technical Specifications

• Compatibility: Designed specifically for the Epson EcoTank L3110. It is often cross-compatible with L-series models including L3100, L3115, L3116, L3150, L3210, L3250, and M2120.
• Part Numbers: Known to correspond with Epson part numbers 2188205 or 2193086.
• Resolution & Performance: Engineered to meet or exceed original OEM standards (generally supporting 600 x 1200 dpi), ensuring clear, crisp, and color-accurate scans.
• Scanner Cable: Uses a 17-pin flat flexible cable (FFC) to transfer data between the unit and the motherboard.

3. Key Features and Benefits

• Cost-Effective Repair: Allows users to fix scanner issues without replacing the entire printer, saving significant costs.
• High-Quality Imaging: Restores full-color resolution and scan sharpness, ideal for high-volume copying environments.
• Durable Build: Manufactured with high-quality components to ensure smooth movement and long-term durability.
• Pre-Tested: Many third-party sellers offer refurbished, tested, or new "original-compatible" modules that are ready to install.

4. Compatibility Details

• Epson EcoTank: L3100, L3101, L3110, L3115, L3116, L3150, L3152, L3156, L3210, L3250, L4150, L6160.
• Epson M-Series: M2120, M2140.
